12" Inch Caster 3307 lbs Fixed Cast iron polyurethane Top Plate

12" Inch Caster 3307 lbs Fixed Cast iron polyurethane Top Plate

Item Name: 12inch-Caster-001

Wheel Diameter: 300mm

Wheel Width: 75mm

Wheel Diameter: 12" Inch = 300mm

Overall Height: 365mm

Overall Height Inch: 14.370"

Mounting Type: Top Plate

Top Plate Size: 200mm x 153mm Top Plate: 14mm+housing: 10mm

Hole distance: 160mm x 90mm

Wheel Core: Cast iron polyurethane

Tire: Cast iron polyurethane

Bearing type: Precision double ball bearing

Load Capacity: 3307 lb

Mounting: Fixed

Temperature Range: -40 to 180 F

Imagine your office chair has no wheel caster, you would be carrying it right and left, install 12inch-Caster-001 instead. This caster is rolled on a wheel that has 300mm diameter/11.811" inch inches. The thickness of the wheel is 75mm or 2.953" inch. The Caster with the wheel from end to end is 365mm = 14.370" inch. Top Plate is the method of installing the caster to your equipment, the dimensions are 200mm x 153mm Top Plate: 14mm+housing: 10mm with the holes distance of 160mm x 90mm. The caster core is made of Cast iron polyurethane and has a Cast iron polyurethane tire with a low friction Precision double ball bearing. Bearing in mind that every caster wheel has the load capacity of 3307 lb with a Fixed type. Last and not least the temperature range = -40 to 180 F. Remember, you will have to buy the 12inch-Caster-001 in order to have it :).
