KCW Casters

3" Inch Caster 132 lbs Swivel and Center Locking Plastic Top Plate

3" Inch Caster 132 lbs Swivel and Center Locking Plastic Top Plate

Regular price $3.14 USD
Regular price Sale price $3.14 USD
Sale Sold out
SKU: 3inch-Lock-Swivel-Caster-024
3" Inch Caster 132 lbs Swivel and Center Brake Plastic Top Plate
  • Item Name: 3inch-Lock-Swivel-Caster-024
  • Wheel Diameter: 75mm
  • Wheel Width: 21mm
  • Wheel Diameter: 3" Inch = 75mm
  • Overall Height: 93mm
  • Overall Height Inch: 3.661"
  • Mounting Type: Top Plate
  • Top Plate Size: 65mm x 54mm
  • Hole distance: 51mm x 38mm
  • Wheel Core: Plastic
  • Tire: Plastic
  • Load Capacity: 132 lb
  • Mounting: Swivel and Center Locking
  • Temperature Range: -40 to 180 F

  • Mounting the 3inch-Lock-Swivel-Caster-024 Wheel Caster can make your life easier, push or pull your new project on wheels. This caster is rolled on a wheel that has 75mm diameter/2.953" inch inches. The thickness of the wheel is 21mm or .827" inch. The overall height of the caster is 93mm or 3.661" inch. Top Plate is the method of installing the caster to your equipment, the dimensions are 65mm x 54mm with the holes distance of 51mm x 38mm. Low drag was achieved by a Plastic core on a Plastic tire spinning freely with a -. Here come the maximum load that should be applied on every wheel, remember to add safety factor, when calculating the load capacity 132 lb with a Swivel and Center Locking type. Temperature range = -40 to 180 F. Remember, you will have to buy the 3inch-Lock-Swivel-Caster-024 in order to have it :).
