4" Inch Caster 441 lbs Fixed Polyvinyl Chloride Top Plate

4" Inch Caster 441 lbs Fixed Polyvinyl Chloride Top Plate

Item Name: 4inch-Caster-004

Wheel Diameter: 100mm

Wheel Width: 50mm

Wheel Diameter: 4" Inch = 100mm

Overall Height: 142mm

Overall Height Inch: 5.591"

Mounting Type: Top Plate

Top Plate Size: 100mm x 115mm

Hole distance: 75mm x 85mm

Wheel Core: Polyvinyl Chloride

Tire: Polyvinyl Chloride

Bearing type: Double ball beaing

Load Capacity: 441 lb

Mounting: Fixed

Temperature Range: -40 to 180 F

Whatever you are building needed to be on wheels, here come the 4inch-Caster-004. This wheel caster has a wheel diameter of 100mm or 3.937" inch in inches. The wheel has a width of 50mm=1.969" inch. The Caster with the wheel from end to end is 142mm = 5.591" inch. Mounted via a Top Plate that has the size of 100mm x 115mm and the holes distance of 75mm x 85mm. The caster core is made of Polyvinyl Chloride and has a Polyvinyl Chloride tire with a low friction Double ball beaing. Here come the maximum load that should be applied on every wheel, remember to add safety factor, when calculating the load capacity 441 lb with a Fixed type. Last and not least the temperature range = -40 to 180 F. Buy the 4inch-Caster-004 now, just add the quantity to basket and click on Checkout.
