4" Inch Caster 661 lbs Swivel and Center Locking Cast Iron and Polyurethane Top Plate

4" Inch Caster 661 lbs Swivel and Center Brake Cast Iron and Polyurethane Top Plate

Item Name: 4inch-Lock-Swivel-Caster-008

Wheel Diameter: 100mm

Wheel Width: 50mm

Wheel Diameter: 4" Inch = 100mm

Overall Height: 150mm

Overall Height Inch: 5.906"

Mounting Type: Top Plate

Top Plate Size: 115mm x 100mm x 6mm

Hole distance: 72mm x 85mm

Wheel Core: Cast Iron and Polyurethane

Tire: Cast Iron and Polyurethane

Bearing type: Roller bearing

Load Capacity: 661 lb

Mounting: Swivel and Center Locking

Temperature Range: -40 to 180 F

You need 4inch-Lock-Swivel-Caster-008 to have your office desk, equipment or even a machine to easily roll them around. This caster is rolled on a wheel that has 100mm diameter/3.937" inch inches. Dimensions of the caster wheel is 50mm (1.969" inch). The Caster with the wheel from end to end is 150mm = 5.906" inch. Mounted via a Top Plate that has the size of 115mm x 100mm x 6mm and the holes distance of 72mm x 85mm. The Roller bearing design will enable the Cast Iron and Polyurethane tire to roll easily with a core made of Cast Iron and Polyurethane. Bearing in mind that every caster wheel has the load capacity of 661 lb with a Swivel and Center Locking type. Last and not least the temperature range = -40 to 180 F. Remember, you will have to buy the 4inch-Lock-Swivel-Caster-008 in order to have it :).
