4" Inch Caster 88 lbs Swivel Polyvinyl Chloride Top Plate

4" Inch Caster 88 lbs Swivel Polyvinyl Chloride Top Plate

Item Name: 4inch-Swivel-Caster-034

Wheel Diameter: 100mm

Wheel Width: 27mm

Wheel Diameter: 4" Inch = 100mm

Overall Height: 130mm

Overall Height Inch: 5.118"

Mounting Type: Top Plate

Top Plate Size: 76mm x 76mm

Hole distance: 57mm x 57mm

Wheel Core: Polyvinyl Chloride

Tire: Polyvinyl Chloride

Bearing type: Plain bearing

Load Capacity: 88 lb

Mounting: Swivel

Temperature Range: -40 to 180 F

Don't think too much, use 4inch-Swivel-Caster-034 to get your DIY move and manuver around. Diameter of the caster wheel is a metric standard 100mm that is equal to 3.937" inch with imperial units. The thickness of the wheel is 27mm or 1.063" inch. The Caster with the wheel from end to end is 130mm = 5.118" inch. Mounted via a Top Plate that has the size of 76mm x 76mm and the holes distance of 57mm x 57mm. Low drag was achieved by a Polyvinyl Chloride core on a Polyvinyl Chloride tire spinning freely with a Plain bearing. Here come the maximum load that should be applied on every wheel, remember to add safety factor, when calculating the load capacity 88 lb with a Swivel type. Temperature range = -40 to 180 F. Remember, you will have to buy the 4inch-Swivel-Caster-034 in order to have it :).
