5" Inch Caster 507 lbs Fixed Thermoplastic Rubber Top Plate

5" Inch Caster 507 lbs Fixed Thermoplastic Rubber Top Plate

Regular price $17.72 USD
Regular price Sale price $17.72 USD
Sale Sold out
SKU: 5inch-Caster-006
5" Inch Caster 507 lbs Fixed Thermoplastic Rubber Top Plate
  • Item Name: 5inch-Caster-006
  • Wheel Diameter: 125mm
  • Wheel Width: 50mm
  • Wheel Diameter: 5" Inch = 125mm
  • Overall Height: 166mm
  • Overall Height Inch: 6.535"
  • Mounting Type: Top Plate
  • Top Plate Size: 100mm x 115mm
  • Hole distance: 75mm x 85mm
  • Wheel Core: Thermoplastic Rubber
  • Tire: Thermoplastic Rubber
  • Bearing type: Double ball beaing
  • Load Capacity: 507 lb
  • Mounting: Fixed
  • Temperature Range: -40 to 180 F

  • Wheel casters like the 5inch-Caster-006 are used to roll your built machine or equipment back and forth. Diameter of the caster wheel is a metric standard 125mm that is equal to 4.921" inch with imperial units. The thickness of the wheel is 50mm or 1.969" inch. The overall height of the caster is 166mm or 6.535" inch. Mounted via a Top Plate that has the size of 100mm x 115mm and the holes distance of 75mm x 85mm. Rolling with a wheel core material of Thermoplastic Rubber and a Thermoplastic Rubber tire rolled over Double ball beaing. Here come the maximum load that should be applied on every wheel, remember to add safety factor, when calculating the load capacity 507 lb with a Fixed type. Last and not least the temperature range = -40 to 180 F. Enjoy our 5inch-Caster-006, we wish all the best in your project.
