5" Inch Caster 838 lbs Fixed Cast Iron and Polyurethane Top Plate

5" Inch Caster 838 lbs Fixed Cast Iron and Polyurethane Top Plate

Regular price $18.00 USD
Regular price Sale price $18.00 USD
Sale Sold out
SKU: 5inch-Caster-022
5" Inch Caster 838 lbs Fixed Cast Iron and Polyurethane Top Plate
  • Item Name: 5inch-Caster-022
  • Wheel Diameter: 125mm
  • Wheel Width: 50mm
  • Wheel Diameter: 5" Inch = 125mm
  • Overall Height: 175mm
  • Overall Height Inch: 6.890"
  • Mounting Type: Top Plate
  • Top Plate Size: 115mm x 100mm x 6mm
  • Hole distance: 72mm x 85mm
  • Wheel Core: Cast Iron and Polyurethane
  • Tire: Cast Iron and Polyurethane
  • Bearing type: Roller bearing
  • Load Capacity: 838 lb
  • Mounting: Fixed
  • Temperature Range: -40 to 180 F

  • You need 5inch-Caster-022 to have your office desk, equipment or even a machine to easily roll them around. This wheel caster has a wheel diameter of 125mm or 4.921" inch in inches. The wheel has a width of 50mm=1.969" inch. The overall height of the caster is 175mm or 6.890" inch. This wheel caster can be mounted using a Top Plate with the dimensions of 115mm x 100mm x 6mm and holes distance of 72mm x 85mm. The Roller bearing design will enable the Cast Iron and Polyurethane tire to roll easily with a core made of Cast Iron and Polyurethane. Here come the maximum load that should be applied on every wheel, remember to add safety factor, when calculating the load capacity 838 lb with a Fixed type. Last and not least the temperature range = -40 to 180 F. Remember, you will have to buy the 5inch-Caster-022 in order to have it :).
