5" Inch Caster 838 lbs Swivel and Center Locking Cast Iron and Polyurethane Top Plate

5" Inch Caster 838 lbs Swivel and Center Brake Cast Iron and Polyurethane Top Plate

Item Name: 5inch-Lock-Swivel-Caster-009

Wheel Diameter: 125mm

Wheel Width: 50mm

Wheel Diameter: 5" Inch = 125mm

Overall Height: 175mm

Overall Height Inch: 6.890"

Mounting Type: Top Plate

Top Plate Size: 115mm x 100mm x 6mm

Hole distance: 72mm x 85mm

Wheel Core: Cast Iron and Polyurethane

Tire: Cast Iron and Polyurethane

Bearing type: Roller bearing

Load Capacity: 838 lb

Mounting: Swivel and Center Locking

Temperature Range: -40 to 180 F

You need 5inch-Lock-Swivel-Caster-009 to have your office desk, equipment or even a machine to easily roll them around. This wheel caster has a wheel diameter of 125mm or 4.921" inch in inches. The wheel has a width of 50mm=1.969" inch. The Caster with the wheel from end to end is 175mm = 6.890" inch. Mounted via a Top Plate that has the size of 115mm x 100mm x 6mm and the holes distance of 72mm x 85mm. Rolling with a wheel core material of Cast Iron and Polyurethane and a Cast Iron and Polyurethane tire rolled over Roller bearing. Here come the maximum load that should be applied on every wheel, remember to add safety factor, when calculating the load capacity 838 lb with a Swivel and Center Locking type. Last and not least the temperature range = -40 to 180 F. Enjoy our 5inch-Lock-Swivel-Caster-009, we wish all the best in your project.
