KCW Casters

5" Inch Caster 838 lbs Swivel and Upper Locking Cast Iron and Polyurethane Top Plate

5" Inch Caster 838 lbs Swivel and Upper Locking Cast Iron and Polyurethane Top Plate

Regular price $30.75 USD
Regular price Sale price $30.75 USD
Sale Sold out
SKU: 5inch-Lock-Swivel-Caster-011
5" Inch Caster 838 lbs Swivel and Upper Brake Cast Iron and Polyurethane Top Plate
  • Item Name: 5inch-Lock-Swivel-Caster-011
  • Wheel Diameter: 125mm
  • Wheel Width: 50mm
  • Wheel Diameter: 5" Inch = 125mm
  • Overall Height: 175mm
  • Overall Height Inch: 6.890"
  • Mounting Type: Top Plate
  • Top Plate Size: 115mm x 100mm x 6mm
  • Hole distance: 72mm x 85mm
  • Wheel Core: Cast Iron and Polyurethane
  • Tire: Cast Iron and Polyurethane
  • Bearing type: Roller bearing
  • Load Capacity: 838 lb
  • Mounting: Swivel and Upper Locking
  • Temperature Range: -40 to 180 F

  • Imagine your office chair has no wheel caster, you would be carrying it right and left, install 5inch-Lock-Swivel-Caster-011 instead. Diameter of the caster wheel is a metric standard 125mm that is equal to 4.921" inch with imperial units. Dimensions of the caster wheel is 50mm (1.969" inch). The overall height of the caster is 175mm or 6.890" inch. This wheel caster can be mounted using a Top Plate with the dimensions of 115mm x 100mm x 6mm and holes distance of 72mm x 85mm. The Roller bearing design will enable the Cast Iron and Polyurethane tire to roll easily with a core made of Cast Iron and Polyurethane. Each caster will carry the load of 838 lb and is Swivel and Upper Locking type. Last and not least the temperature range = -40 to 180 F. Remember, you will have to buy the 5inch-Lock-Swivel-Caster-011 in order to have it :).
