KCW Casters

6" Inch Caster 617 lbs Fixed Thermoplastic Rubber Top Plate

6" Inch Caster 617 lbs Fixed Thermoplastic Rubber Top Plate

Regular price $21.11 USD
Regular price Sale price $21.11 USD
Sale Sold out
SKU: 6inch-Caster-006
6" Inch Caster 617 lbs Fixed Thermoplastic Rubber Top Plate
  • Item Name: 6inch-Caster-006
  • Wheel Diameter: 150mm
  • Wheel Width: 50mm
  • Wheel Diameter: 6" Inch = 150mm
  • Overall Height: 195mm
  • Overall Height Inch: 7.677"
  • Mounting Type: Top Plate
  • Top Plate Size: 100mm x 115mm
  • Hole distance: 75mm x 85mm
  • Wheel Core: Thermoplastic Rubber
  • Tire: Thermoplastic Rubber
  • Bearing type: Double ball beaing
  • Load Capacity: 617 lb
  • Mounting: Fixed
  • Temperature Range: -40 to 180 F

  • Mounting the 6inch-Caster-006 Wheel Caster can make your life easier, push or pull your new project on wheels. This wheel caster has a wheel diameter of 150mm or 5.906" inch in inches. The thickness of the wheel is 50mm or 1.969" inch. The Caster with the wheel from end to end is 195mm = 7.677" inch. This wheel caster can be mounted using a Top Plate with the dimensions of 100mm x 115mm and holes distance of 75mm x 85mm. Low drag was achieved by a Thermoplastic Rubber core on a Thermoplastic Rubber tire spinning freely with a Double ball beaing. Bearing in mind that every caster wheel has the load capacity of 617 lb with a Fixed type. Temperature range = -40 to 180 F. Buy the 6inch-Caster-006 now, just add the quantity to basket and click on Checkout.
