8" Inch Caster 772 lbs Swivel and Upper Locking Polyurethane and Cast iron core Top Plate

8" Inch Caster 772 lbs Swivel and Upper Brake Polyurethane and Cast iron core Top Plate

Item Name: 8inch-Lock-Swivel-Caster-004

Wheel Diameter: 200mm

Wheel Width: 50mm

Wheel Diameter: 8" Inch = 200mm

Overall Height: 265mm

Overall Height Inch: 10.433"

Mounting Type: Top Plate

Top Plate Size: 140mm x 108mm

Hole distance: 105mm x 75mm

Wheel Core: Polyurethane and Cast iron core

Tire: Polyurethane and Cast iron core

Bearing type: Ball bearing

Load Capacity: 772 lb

Mounting: Swivel and Upper Locking

Temperature Range: -40 to 180 F

Mounting 8inch-Lock-Swivel-Caster-004 is the solution of making your project to move around by pushing. Diameter of the caster wheel is a metric standard 200mm that is equal to 7.874" inch with imperial units. Dimensions of the caster wheel is 50mm (1.969" inch). The caster dimensions heightwise is 265mm/10.433" inch. Top Plate is the method of installing the caster to your equipment, the dimensions are 140mm x 108mm with the holes distance of 105mm x 75mm. The Ball bearing design will enable the Polyurethane and Cast iron core tire to roll easily with a core made of Polyurethane and Cast iron core. Each caster will carry the load of 772 lb and is Swivel and Upper Locking type. The temperature range is -40 to 180 F. Buy the 8inch-Lock-Swivel-Caster-004 now, just add the quantity to basket and click on Checkout.
